LOT OF THREE ORIGINAL SMITH & WESSON PROTOTYPE DRAWINGS.

A unique and most unusual grouping of perspective schematic drawings from one of the most famous firearm companies in the world. Drafted a leather-like textured medium paper images represent 1) Jigg to drill frame for yoke, stud and stop dated August 23, 1894, 2) Fixture to round edges of checking on thumb piece, dated December 26, 1901 and 3) Fixtures to cherry milling thumb pieces dated December 14, 1901. SIZE: Sight size 15-1/2″ w x 11-1/2″ h. CONDITION: Near excellent. Paper has yellowed slightly over time but not a distraction to these historically significant pieces. 1-13680 (500-1,000) – Lot 3597
